Highlight: Digital balancing valve
Product introduction:
The SP15F digital locking balancing valve is a new type of energy-saving valve with special functions. Equipped with a
digital display for opening degree, a digital locking device, and a small pressure-measuring valve for flow measurement, this
valve allows intuitive adjustment to any position. Suitable for various liquid pipeline systems, it is a relatively ideal new
energy-saving valve. Featuring a calibrated digital display, the valve can be intuitively adjusted to any position and locked in
place. It is mainly applied in heating pipeline systems for industrial and civil buildings. At present, hydraulic imbalance issues
exist in some pipeline networks, and the balancing valve provides a solution to this problem. It can accurately regulate
pressure drop and flow, thereby improving the liquid flow condition in the pipeline network, achieving liquid balance in the
network, and saving energy. Even in the renovation of dual-pipeline projects, the application of this valve can still save
energy and achieve favorable results.
Product technical parameters:
| Nominal Diameter DN (mm) | 15~200 |
| Nominal Pressure PN (MPa) | 1.6 |
| Test Pressure (MPa) | Strength (water) | 2.4 |
| | Enclose (Water) | 1.76 |
| Main Components | Body | WCB/CF8/CF8M |
| | Valve ball | Stainless steel/Carbon steel |
| | Seat | PTFE |
| | Packing | Soft graphite |
| | Shaft | 2Cr13 |
| | Handle | Ductile iron |
| Working temperature | ≤150℃ |
| Medium suitable | Water, oil, steam |
Product features
1. Digital control and precise adjustment enhance the operating efficiency and stability of the system.
2. Reducing pipeline resistance improves the flow state of air and water in the system, ensuring the uniform distribution of indoor temperature.
3. Remote control via mobile apps and other means enables remote adjustment and monitoring, upgrading the intelligence level of the equipment.
4. It features a simple structure, convenient maintenance, long service life, and low cost.
